High-Speed Pet Underpads Packaging Machine
A packaging machine mainly for packing diapers & baby pants products with high-speed & semi-automatic main features. When products being detected by the Packaging Machine, it will undergo procedures such as: automatic compression, stacked-products/pieces pushing, suction and the final stage of bottom gusset folding, heat-sealing and waste clearance procedures.
Mechanical Features:
1. Patent sealing and gusset-folding mechanism.
Precise sealing effect with well adjusted sealing tempreature , with efficient and convenient mechanical size-changing procedure for different packaging, as well as simple and efficient mechanical engineering design. By far the most stable diaper sealing solution.
2. Multi-Servo drive and high mechanical stability.
The adoption of Mitsubishi or AB motion-controlled PLC and Bus Servo System ensures the stability and efficiency of pet underpads production, with the qualified rate reaching as high as 99%.
3. Ease of transportation & mobility.
The mechanical equipment can be transported from one spot to another when it needs to locate at a new different production area within.
4. Able to undergo fully-automatic upgrading and integration
Easily integrates with Stacking Machine for semi- to fully-automatic bagging.
Picture Preview:
Technical Parameters:
Applicable Packaging Specifications: | width:120~400(customizable) height: 90~230(customizable) length:150~500(customizable) |
Texture of Bags: | Suitable For Manual Sealing & Applicable to Nonwoven Materials |
Electrical System: | Motion controlled system, touch screen,servo drive (9 axles) |
Installed Power: | 22.5 KW |
Power Requirement: | 380V/50HZ 3*10㎜² 2*6㎜²5-core power cord |
Air Pressure Requirement: | 0.5Mpa |
Machine Weight | 2000Kg |
Machine Dimension (length×width×height) | 3300×1900×2400 |
